GNN XB-52DL Kuulapää +QR levy Sunwayfoto /HOG Saddle

400.00 (322.58 alv 0%)

SKU: gnn-xb-52dl-Kit Categories: , Tags: , , , , ,
hog saddle logotype mildot finland


Low-Profile Ball Head with Duo-lever Clamp

*Includes One FREE MARC-QD Quick Detach Plate, $40 value. The dual mounting bolt design is a superior, zero twist connection point.

The new GNN XB-52DL is the perfect balance between weight, load capacity, and super low-profile height. These ball head specs are unmatched. The GNN XB-52DL is ideal for weight conscious individuals who still require a full featured ball head for tripod shooting. We made the GNN XB-52DL even shorter, by machining off the neck of the ball head (creating the proprietary GNN series). This reduces damaging stress/leverage to internal parts, increases stability, yet still allows for 24° of elevation adjustment, with approximately 50° of total vertical travel. The Sunwayfoto GNN XB-52DL Low-Profile Ball Head with Duo-lever Clamp is based on the original XB-52, and we replaced the Screw-Knob Clamp with DLC-60 Screw/Lever Combo Clamp. The screw knob side is for adjusting the width of the clamp, and the lever side is for locking the clamp quickly. The XB-52DL Low Profile Ball Head from Sunwayfoto is the larger of two ball heads in the XB line of low profile ball heads from Sunwayfoto. It features a very low center of gravity, a very high load capacity of 132 pounds, and an improved ball head design for smoother movements when changing tripod shooting position.


Features include:
  • Locking System is located on the side of the ball head, instead of the bottom. The whole center of gravity is lowered more than 15%.
  • Adopts geared locking structure, higher locking strength.
  • Specially designed  panning base, smooth operation.
  • Elliptical ball for progressive resistance and avoiding suddenly sliding down.
  • All metal knobs for reliability and long term durability.
  • Special structure makes it the lightest of its class.
  • 360° panning movement with calibrated precision, precisely capture overlapping panoramic images.
  • Compatible with Really Right Stuff (RRS), Wimberley, Jobu Design, Arca Swiss, Kirk Enterprises, Markins, Photo Clam etc.
  • Ideal for Gitzo, SLIK, Manfrotto, Sirui, Benro, RRS tripods.


Model  GNN XB-52DL
Ball Diameter  52mm
Pan Base Diameter     68mm
Height 85mm
Weight  0.73kg
Max. Load  59kg
UNC  3/8-16
Clamp Type  Screw/Lever Combo Clamp 38mm Arca-Swiss





Additional information

Weight 0.85 kg
Dimensions 15 × 15 × 15 cm


HOG Saddle / Shadowtech

Shadowtech valmistaa kestäviä tuotteita Amerikoissa HOG saddle nimellä, laatu on niin hyvää että heidän tuoteista on tullut se mihin muut verrataan. Monet ammattilaiset ja metsästäjät joka haluaa luotettavia ja kestäviä ratkaisuja valitsee Shadowtechin tuotteet. Linkki Shadowtech kotisivulle : Linkki asiakaspalautteihin : Linkki FAQ (Usein kysytty kysymykset) :
