Long-range shooting will test your limits with every shot, which is where the RX®-2800 TBR®/W Alpha IQ™ digital rangefinder comes in. With 1/2-yard accuracy out to 2,800 yards, 7x magnification, and an easy-to-read red OLED display, this lightning-quick rangefinder is guaranteed to stretch your skills. The Alpha IQ™ engine makes ranging smaller targets quicker than ever before, while our True Ballistic Range® (TBR®) technology takes into account the angle of your shot and your rifle’s ballistics to put you dead on every time. Go farther even faster with the new RX®-2800 TBR®/W Alpha IQ™ digital rangefinder.
Features
Line of Sight (LOS) Mode – Calculates the distance to a target in a straight line, regardless of any incline or decline.
True Ballistic Range (TBR) Mode – Uses 25 selectable ballistics groups to calculate precise shoot-to-ranges of up to 800 yards, taking into account factors such as distance, angle, and bullet characteristics. This mode can also calculate a hold value for a 10-mph wind at a 90-degree angle.
Last Target – Guarantees that the rangefinder identifies the most distant target along the laser’s trajectory, preventing inaccuracies caused by adverse weather conditions like rain, snow, or fog.
Red OLED Display – Uses bright red characters and have adjustable brightness setting. This display technology also enables best in class light transmission for use in low light conditions.
Selectable Reticles – Offers a variety of reticles to choose from to fit any use or preference.
Tripod Ready – Built-in 1/4-20 rotatable tripod adapter port makes it easy to mount to a tripod.
Waterproof and Fogproof – Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures and elevation changes, so the internals of the optics stay moisture free and crystal clear for life.
Specifications
Battery Type | CR123 |
---|---|
Display Color | OLED (Red Display) |
Flightpath | No |
Magnification | 7 |
Prism Lock | No |
Rifle Angle Compensation | TBR/W |
Trophy Scale | No |
Tripod Compatible (1/4-20) | Yes |
True Ballistic Range – Wind (TBR-W) | Yes |
Horizontal Distance (TRIG-H) | No |
Archer’s Advantage | No |
Bow Mode | No |
True Golf Range (TGR) | No |
Length (in) | 4.3 |
Width (in) | 1.5 |
Height (in) | 3 |
Weight (oz) | 7.9 |
Objective Diameter (mm) | 27 |
Linear FOV (ft@1000 yd) | 318 |
Angular FOV (Degrees) | 6.3 |
Eye Relief (mm) | 16 |
Min Diopter (dpt) | -3 |
Max Diopter (dpt) | 3 |
Light Transmission (%) | 85 |
Battery Life (Actuations) | >3000 |
Accuracy to 125 (yd) | .5 |
Accuracy to 1000 (yd) | 2 |
Accuracy above 1000 (yd) % | .2 |
Max Range – Deer (yd) | 1800 |
Max Range – Trees (yd) | 2400 |
Max Range – Reflective (yd) | 2800 |
Max Range – Golf Flag (yd) | 0 |
Min Range (yd) | 6 |
Laser Classification | IEC 3R |
Additional information
Weight | 0.4 kg |
---|---|
Dimensions | 20 × 15 × 10 cm |
